3.2.38. Remote Association Activation Command Class, version 1 [OBSOLETED]

Warning

THIS COMMAND CLASS VERSION HAS BEEN OBSOLETED

New implementations MUST NOT use this command class.

The Remote Association Activation Command Class is used to remote activations of Association grouping identifiers in other nodes.

Mandatory requirement: Both ‘local’ and ‘remote’ node MUST implement the Association Command Class as illustrated below. In addition the ‘local’ node MUST implement the Remote Association Configuration Command Class as ‘Supported’.

The Remote Association Activation Command Class and the Remote Association Configuration Command Class are additions to the functionality to the existing Association Command Class.

Remote Association Activation Command Class

Figure 3.25 Remote Association Activation Command Class

The Remote Association Configuration Command Class enables a 1st node (any node) to configure a 2nd node (local node) to issue a Remote Association Activate Command to a 3rd node (remote node), which instruct the 3rd node to activate one of its locally stored association group identifiers as defined by the Association Command Class.

3.2.38.1. Remote Association Activate Command

The Remote Association Activate Command is used to instruct a ’remote’ node to activate one of its locally stored association group identifiers as defined by the Association Command Class. This will subsequently generate a number of Commands being issued from the ‘remote node to the NodeIDs associated to the grouping identifier.

Table 3.145 Remote Association Activate Command

7

6

5

4

3

2

1

0

Command Class = COMMAND_CLASS_REMOTE_ASSOCIATION_ACTIVATE (0x7C)

Command = REMOTE_ASSOCIATION_ACTIVATE (0x01)

Grouping identifier

Grouping identifier (8 bits)

This group identifier used to specify the grouping identifier on the remote node.
