3.2.39. Remote Association Configuration Command Class, version 1 [OBSOLETED]

Warning

THIS COMMAND CLASS VERSION HAS BEEN OBSOLETED

New implementations MUST NOT use this command class.

The Remote Association Configuration Command Class is used to configuration of the Remote Association Activation Command Class.

Mandatory requirement: Both ‘local’ and ‘remote’ node MUST implement the Association Command Class as ‘supported’. In addition the ‘local’ node MUST implement the Remote Association Configuration Command Class as ‘supported’ and the node used to make the configuration (‘any node’ in the description below) MUST implement it as ‘controlled’.

The Remote Association Configuration Command Class is an addition to the functionality of the existing Association Command Class.

Remote Association Configuration Command Class

Figure 3.26 Remote Association Configuration Command Class

The Remote Association Configuration Command Class enables a 1st node (Any node) to configure a 2nd node (Local node) to issue a Remote Association Activate Command to a 3rd node (Remote node), which instructs the 3rd node to activate one of its locally stored association group identifiers as defined by its Association Command Class.

3.2.39.1. Remote Association Configuration Set Command

The Remote Association Configuration Set Command links two nodes’ ‘Association Command Class’ defined grouping identifiers together. It allows one node (local node) to use its grouping identifiers to control a second node’s (remote node) grouping identifiers, using the Remote Association Activation Command Class.

Table 3.146 Remote Association Configuration Set Command

7

6

5

4

3

2

1

0

Command Class = COMMAND_CLASS_REMOTE_ASSOCIATION (0x7D)

Command = REMOTE_ASSOCIATION_CONFIGURATION_SET (0x01)

Local Grouping identifier

Remote NodeID

Remote Grouping identifier

Local Grouping identifier (8 bits)

Like in the Association Command Class, the Local Grouping identifier is used to specify the grouping identifier on the local node.

A Local grouping identifier = 0x0 will erase all links between local and remote grouping identifiers.

Remote NodeID (8 bits)

This NodeID used to specify the Node, which should receive the Remote Association Activate Command.

A NodeID = 0x0 will remove a link between the specified local grouping identifier and a remote grouping identifier.

Remote Grouping identifier (8 bits)

This group identifier used to specify the grouping identifier on the remote node.

3.2.39.2. Remote Association Configuration Get Command

The Remote Association Configuration Get Command is used to request the link between a Local Grouping identifier and a Remote Grouping identifier on a node.

The Remote Association Configuration Report Command MUST be returned in response to this command.

This command MUST NOT be issued via multicast addressing.

A receiving node MUST NOT return a response if this command is received via multicast addressing. The Z-Wave Multicast frame, the broadcast NodeID and the Multi Channel multi-End Point destination are all considered multicast addressing methods.

Table 3.147 Remote Association Configuration Get Command

7

6

5

4

3

2

1

0

Command Class = COMMAND_CLASS_REMOTE_ASSOCIATION (0x7D)

Command = REMOTE_ASSOCIATION_CONFIGURATION_GET (0x02)

Local Grouping identifier

Local Grouping identifier (8 bits)

Like in the Association Command Class, the Local Grouping identifier is used to specify the grouping identifier on the local node.

3.2.39.3. Remote Association Configuration Report Command

The Remote Association Configuration Report Command returns the remote NodeID and the grouping identifier.

Table 3.148 Remote Association Configuration Report Command

7

6

5

4

3

2

1

0

Command Class = COMMAND_CLASS_REMOTE_ASSOCIATION (0x7D)

Command = REMOTE_ASSOCIATION_CONFIGURATION_REPORT (0x03)

Local Grouping identifier

Remote NodeID

Remote Grouping identifier

Local Grouping identifier (8 bits)

This group identifier used to specify the grouping identifier on the local node

Remote NodeID (8 bits)

This NodeID used to specify the remote node that the Remote Association Activate Command is sent to. If no link is established between the Local Grouping Identifier and a Remote Grouping Identifier, the Remote NodeID will return zero (0x0)

Remote Grouping identifier (8 bits)

This Remote grouping identifier used to specify the grouping identifier on the remote node that should be activated.
